ABM600 Baby Monitor – Technical Specifications & User Guide

📦 Technical Parameters

• Model: ABM600

• Camera Resolution: 1280 × 720P

• Display Resolution: 800 × 480

• Display Size: 3.5 inches

• Camera Sensor: 1/4 CMOS

• Viewing Angle: 60°

• Transmission Range: Up to 300m (outdoors), ~30m indoors

• Transmission Method: FHSS (Frequency Hopping Spread Spectrum)

• Camera Power Consumption: 1.5W

• Display Power Consumption: 1.6W

• Battery Capacity: 1500mAh

• Night Vision: Automatic infrared

• Lullabies: 8 built-in songs

• Feeding Timer: Supported

• Temperature Monitoring: Yes (Alarm for <20℃ or >30℃)

• Crying Detection Alarm: Supported

• Two-Way Talk: Supported

📐 Dimensions & Weight

• Display Unit: 133mm (L) × 76mm (W) × 20mm (T)

• Camera Unit: 66mm (Dia.) × 108mm (H)

• Net Weights: Provided separately for display and camera

🔌 Power & Safety

• Input Voltage: 100 – 240V

• Shell Material: Flame-retardant ABS

• Sensor Placement: Center-positioned photodiode; performs reliably in high-temperature and humid conditions

• Note: Avoid placing the units too close to each other to prevent audio feedback ("whistling").

🧭 Function Overview

1. Real-Time Audio & Video Transmission
   View and hear your baby live via the handheld display. Use the intercom feature to speak to your baby remotely.

2. Feeding Reminder
   Set custom feeding intervals (e.g., every 30 minutes), and receive alerts via image and sound.

3. Lullabies
   Play up to 8 soothing lullabies remotely from the display to comfort your baby.

4. Temperature Display & Alerts
   Monitor room temperature and receive alerts if levels fall below 20°C or rise above 30°C.

5. Dual-Camera Switching
   Supports connection to two baby cameras. Switch manually or enable auto-switching for surveillance between both.

6. VOX Mode (Sound Activation)

   • Default: Off

   • When enabled, the display sleeps after 30 seconds of silence and wakes when sound exceeds the selected sensitivity level (LOW / MED / HIGH).

7. Display Settings

   • Adjustable brightness, volume, temperature unit (°C/°F), time zone, and screen timeout options.

🛠️ Pairing Instructions

Camera Pairing (CAM1 / CAM2):

1. On Camera: Press the power button twice to enter pairing mode (blue light blinks).

2. On Display:

   • Press the M key to enter the menu.

   • Select ‘Add Camera’ and press OK.

   • When pairing is successful, the blue light stops blinking.

Important:

• Each baby unit (CAM) can connect to one display only.

• A single display can pair with up to two baby units.

• CAMs cannot be shared across multiple displays.

🧭 Button Definitions – Display Unit

• Power Button:

  • Long press: Power On/Off

  • Short press: Screen On/Off (audio remains active)

• Intercom Button: Press and hold to speak to baby

• Menu Button (M): Open main menu / Return from submenu

• Directional Keys (↑↓←→): Navigate menu

• OK Button: Confirm selection

• Reset Button: Restart the device

📢 Usage Tips

• Noise Feedback ("Whistling")
  Occurs if the display and camera are too close—ensure distance is maintained.

• Camera Placement:
  Ensure unobstructed view of baby; place at a safe height.

• Environment Note:
  Transmission range may vary depending on wall material and layout.

🎁 Ideal For:

• Monitoring babies while in another room

• Ensuring room temperature is baby-safe

• Offering comfort with lullabies or voice via two-way talk

• Alerting caregivers when baby cries or wakes
